MEDICRAFT

ANALGESIOMETER

MARK - IV

(RADIANT HEAT TYPE)

FOR

ASSAY OF ANALGESICS

The  MEDICRAFT ANALGESIOMETER Mark ≠ IV is an upgraded version of our simple most ANALGESIOMETER Mark-I which is used as a basic instrument in the Pharmacology Laboratories of  Medical College,  Pharmaceutical firms  and Bio-research   centers for the  study of analgesics.

The  MEDICRAFT  ANALGESIOMETER - IV is  an  elementary standard that provides pain stimulus in the tail of rat by radiation  of   heat from  a heated nichrome wire. The intensity  of  pain stimulus   is continuously  variable from  minimum to maximum and is monitored by a meter. The heat producing  wires are  planted along with a specially designed  water   jacket  which also acts as retainer for  ratís  tail  and regulates  the surrounding side areas to room temperature   The intensity control is a solid state device and provides   a  constant heat  at set point ignoring  the  main  line voltage fluctuation  of Ī10% of  220V, A.C line  at which the instrument works.

In addition to the above features, an Electronic Digital Timer Display is provided to measure the response time and a foot switch to start and stop the heating. The inbuilt timer eliminate the need of stop watch thus making free the hands of experimenter.

A Rectangular clear Plexiglas rat carrier is  provided  as    accessories. And one heating element and one  glass   cartridge fuse are supplied as the spares.

All  the MEDICRAFT Products are guaranteed for  12  months  against any manufacturing defects.

Ordering Information



A-10/MARKIV Medicraft Analgesiometer, MarkIV
A-10/RCM Rat Carrier for mice chrome plated 15 cm long, 5 cm diameter
A-10/RCR Rat Carrier for Rats chrome plated

18 cm long, 7 cm diameter

A-10/RPM Rat Carrier for mice square, Perspex 43x43x180mm length adjustable
A-10/RPR Rat Carrier for Rats square, Perspex 70x70x250mm length adjustable
A-10/NCM Nichrome wire Element Heating element

Specification may change without notice for improvement.
