MEDICRAFT

LABRYNTH MAZE

for

Studying Learning in Animals



The MEDICRAFT LABRYNTH MAZE is another version of our simple Maze. The Labrynth Maze contains channel or tunnel which formed number of Y and figures for exploring by the animal like mice and rats.

The Y and channels are connected alternatively in a continuous line. The animal is placed in closed chamber which is the start point. The animal is released by opening the slide door and is allowed to explore. The end point is at the end of the channel. on reaching at the end chamber the cycle ends.



Specification

bulletAnimal Position Indicators on Panel.
bulletA 4 or 5 Digit Electronic Display indicating time in seconds, maximum count 9999 or 99999 seconds.
bulletOver all dimension of the Maze.
for rats 1000 x 600 x 200 mm.
for mice 600 x 300 x 100 mm.
bulletChannel dimension:-
Width Height
for rats 100 mm. 120 mm.
for mice 60 mm. 100mm.
bullet

The apparatus works from 220V., 50 Hz. AC. Only.

Ordering Information



515 R

Medicraft Labrynth Maze for Rats

512 M

Medicraft Labrynth Maze for Mice

Specification may change without notice for improvement.
