MEDICRAFT

ANALGESIOMETER

MARK - I

(RADIANT HEAT TYPE)

FOR

ASSAY OF ANALGESICS



The  MEDICRAFT ANALGESIOMETER Mark≠I is the most needed basic instrument of the Pharmacology Laboratories of Medical College, Pharmaceutical firms and  Bio-research   centers for the  study of analgesics.

The  MEDICRAFT  ANALGESIOMETER is  an  elementary standard  that provides pain stimulus in the tail of rat by radiation  of   heat from  a heated nichrome wire. The intensity  of pain   stimulus   is continuously  variable  from  minimum to maximum and is monitored by a meter. The heat  producing   wires  are  planted along with a specially designed  water   jacket which  also acts as retainer for  ratís  tail  and regulates  the surrounding side areas to room temperature   The intensity control is a solid state device and provides  a constant  heat  at set point ignoring  the  main  line voltage  fluctuation  of Ī10% of  220V,A.C  line  at which the instrument works.

A cylindrical  metallic rat carrier is  provided  as    accessories. A heating  element  and a  glass

cartridge fuse are supplied as the spares.

All  the MEDICRAFT Products are guaranteed for  12  months against any manufacturing defects.



Ordering Information



A-10/MARK-I

Medicraft Analgesiometer, Mark-I

Radiant heat type

A-10/RCM

Rat Carrier for mice chrome plated

15 cm long, 5 cm diameter

A-10/RCR

Rat Carrier for Rats chrome plated

18 cm long, 7 cm diameter

A-10/RPM

Rat Carrier for mice square, Perspex

43x43x180mm length adjustable

A-10/RPR

Rat Carrier for Rats square, Perspex

70x70x250mm length adjustable

A-10/NCM

Nichrome wire Element

Heating element

Specification may change without notice for improvement.
