MEDICRAFT

DIGITAL  DISPLAY

RESPONSE TIME APPARATUS

The MEDICRAFT DIGITAL RESPONSE TIME APPARATUS is designed to measure the TIME interval after which the subject responds as any of the two visual (Red or Green ) and Two aural ( Different Tones ) stimulii is presented.

The Apparatus is a compact portable instrument with sloping operating Panels with a removable screen or partition between operator and subject with Electronics timer of 0.01 second resolution.



SPECIFICATIONS

bullet

Operation from 220 V,  ± 10%, single Phase, 50Hz, A.C.

bullet

Option  for External D.C. Source on request.

bullet

Fully Microprocessor Control.

bullet

Two Visual Stimuli, Red & Green, 10mm Light Emitting Diodes  (L.E.D.) on subject side.

bullet

Two Aural stimulii of different tones.

bullet

Individual controls for each stimulii.

bullet

Four Digit Electronic Display of time, maximum counting 99.99 second with resolution of 0.01 second.

bullet

Power ON-OFF Switch & Indicators.

bullet

Reset to Zero Switch.

bullet

Crystal Controlled Timer at extra cost.

bullet

Removable Screen partition

bullet

Housed in an elegant Rustproof cabinet

ORDERING INFORMATION

651 MP

Medicraft Digital Response Time Apparatus.

Specification may change without notice for improvement.
