MEDICRAFT
ELECTRONIC STIMULATOR
EXPERIMENTAL MODEL
|
|
|
The EXPERIMENTAL MODEL
series 810 of MEDICRAFT STIMULATOR is designed to serve the requirements
mostly needed in the laboratories of Pharmacology, Physiology, Experimental
Medicine, Bio-sciences as well as in Surgery to trace the nerves.
The MEDICRAFT ELECTRONIC
STIMULATOR EXPERIMENTAL MODEL - is a LOW COST, rigid and simple to
operate unit with minimum controls. It is designed to with stand the
POWER-LINE fluctuations and provide 10 spot frequencies with 10
fixed-selectable Pulse-widths, continuously variable output, single or
repetitive - positive or negative pulse, D.C. and with synchronizing input
and output facility.
specification
 |
The
instrument operates from 230 V, ± 10 %, 50 Hz., A.C.
|
|
Provides variable output in four decades from 0
to 150 Volts.
|
|
10 spot frequencies of square wave pulses of 1,
2, 3, 5, 7, 10, 20,50, 100 and 200 per seconds.
|
|
Pulse With or Duration of .05, 0.1, 0.2, 0.5, 1,
2, 5, 10, 20 and 50 milli seconds.
|
|
Positive or negative reversal facility for
output.
|
|
Mono-phasic or Bi-phasic pulses operation
through switch.
|
|
Continuous D.C. from 0 to 150 Volts.
|
|
Stimulus indicator.
|
|
Mains ON indicator.
|
|
5 Volts D.C., for signal Magnet (Marker)
recording.
|
|
Synchronizing output to drive another such unit
or for oscilloscope monitoring or recording.
|
|
Synchronizing input to drive this unit from an
external source.
|
|
Main ON/OFF Switches.
|
|
Housed in a Mild Steel Cabinet duly painted.
|
Approximate Dimensions :
380 x 200 x 200 mm.
Note :- The Experimental Model is
also available with audio monitor, i.e., an output is available at the
output terminals.
|
|
Ordering Information
|
800 - EST |
Medicraft Electronic Stimulator - Student’s
Stimulator. |
|
810 - ESS |
Medicraft Electronic Stimulator -
Senior
Model.
|
|
820 - ESL |
Medicraft Electronic Stimulator -
Super
Lab Model. |
Specification may change without notice for improvement.
|
|
