MEDICRAFT

ELECTRONIC STIMULATOR

The LABORATORY MODEL series 820 of MEDICRAFT STIMULATOR is designed to fulfill the various parameters generally required by an experimentor in the laboratories of Pharmacology, Neuro-Pharmacology Physiology, Experimental Medicine, Bio-sciences, Surgery and such allied field.

 The MEDICRAFT ELECTRONIC STIMULATOR - LABORATORY MODEL is a rigid unit with variable controls to select a pulse of desired repetitive rate, width and amplitude facility to operate from a timer and with synchronizing input and output.

 specification

1. The instrument operates from 230 V, ± 10 %, 50 Hz., A.C.

2. Provides variable output in four decades from 0 to 150 Volts.

3. Frequency :  Continuously variable from 0.1 pulse to 1000 pulses per second in four ranges.

4. Pulse width or duration also continuously variable from 0.05 to 50 milli second in three range.

5. Output polarity reversal facility.

6. Selection of Mono or Bi - phasic pulses.

7. Continuous D.C. from 0 to 150 Volts.

8. Operation through a timer switch.

9. 5V  D.C., for Signal Magnet ( Marker ) drum recording.

10. Stimulus Indicator.

11. Mains ON indicator.

12. Safety fuse.

13. Synchronizing output from frequency section to operate another    such unit for delay operation or for recording or for Oscilloscope Monitoring.

14. Synchronizing input to drive this unit from an external source.

15. Synchronizing output from output or final stage for monitoring or for  recording.
