Finger Tapping Apparatus



The Medicraft finger tapping apparatus has been designed with the specifications provided by Dr. M. M. Ali and Dr. Pramod Kumar of Deptt. Of Nuerotoxocology, Industrial Toxicological Research Centre (I.T.R.C.), Lucknow, a constituent lab of C.S.I.R.

The Medicraft Finger tapping apparatus is helpful in the study of motor speed task performed with a simple counter. The subject taps it with his/her thumb/finger as fast as possible for a preset duration. The instrument is also used for measuring the finger fatigue.

 The Medicraft Finger tapping apparatus is a microprocessor based apparatus designed to provide repeat accuracy and minimise human error. The apparatus contains a variable, down-counting timer which can be set from one to ninety nine seconds. This sets the time duration in which the subject has to tap his/her finger. The apparatus automatically stops counting as soon as the time is over and subsequent finger taps are ignored. This brings in repeat accuracy and minimise the human error in the conventional stopwatch method.



SPECIFICATIONS.

bullet

Operates from 220 ± 10%, 50Hz, A.C.

bullet

Optional, Battery backup in excess of 5 hours, ideal for field operations.

bullet

Variable session duration from 1 to 99 sec. 15 sec default on power on.

bullet

5 – Digit response time display 0.001 second accuracy.

Ordering Information



660

Medicraft Finger Tapping Apparatus

Specification may change without notice for improvement.
