MEDICRAFT

SHUTTLE BOX

for

Study of Avoidance Response

The MEDICRAFT SHUTTLE BOX is designed to study the avoidance behavior of  the rats and mice in the laboratory.

The Medicraft Shuttle Box consists of a rectangular box/chamber which is divided into two sections, Each chamber so formed has its grid floor which can be electrified. The dividing wall is provided with an opening through which the animal crosses over from one chamber to another. This dividing wall and the sides of the chamber are opaque and the top of chamber is a hinged clear transparent plexiglass lid, through which the animal is placed in or removed from the chamber.

Each chamber can be illuminated and a sounder or speaker is at the centre top of the lid to produce acoustical stimulus .

A Controller Unit provides the necessary control functions.

General Features:

bullet

The chambers can be illuminated left or right through  the controller.

bullet

The grid floors of either chamber can be charged through controller from minimum to maximum intensity.

bullet

The level of acoustical  stimulus intensity is also variable.

bullet

The presence of animal  in chamber is indicated on the panel of the controller.

The Controller Unit consists  of all the necessary functional controls :

bullet

Power ON-OFF switch.

bullet

Variable On-Off Time-Period of stimulus presentation.

bullet

Session - Trail    Start - Stop push buttons.

bullet

Left or Right chamber selector knob.

bullet

Independent On-Off switches for acoustical, electrical and visual   stimulus.

bullet

Variable  electrical and audible intensity control knobs.

bullet

Indicators for all the functions provided on the controllerís panel.



Technical specifications:

bullet

The instrument operates from 220 V.AC.,50 Hz.

bullet

Electrical stimulus intensity ,0-150 V. R.m.s. with current limiting.

bullet

Variable acoustical intensity level.

bullet

ON Time-Period,varible,0 to 10 seconds.

bullet

OFF Time-Period,variable,0 to 30 seconds.

bullet

Dimensions:

bullet

Shuttle box : 650X300X350 mm.

bullet

 Working Chambers :  300X250X300.mm.

Ordering Information



657

Medicraft Shuttle Box

Specification may change without notice for improvement.
